Borgo 43 LED 2700K
Matt White 1212031
Forward voltage per product is 3.1V.
spec overview
Lamp Included 1 x 1W LED IP65To ensure you have the correct amount of fittings per driver, please refer to our driver calculator. Alternatively, for more information on drivers, please refer to our Advanced Guide to LED Lights & Drivers.
Optional back box for solid wall installation is supplied with the product.
Specification
| Lamp Required: | No |
|---|---|
| Lumen Output (LM): | 12.2 |
| Colour Temperature (K): | 2700 |
| Max Lamp Type & Wattage: | 1 x 1W LED |
| Switched: | No |
| Dimmable: | Yes |
| Driver Required: | Constant Current 350mA |
| Class: | Class III - Low Voltage |
| Power Connection Type: | Wired In |
| IP Rating: | IP65 |
| Bathroom Zone: | Zone 1, 2, 3 |
| Installation Orientation: | Wall Mount - Vertical |
| Recess Depth (mm): | 75 |
| Cutout Shape: | Square |
| Cutout Length (mm): | 100 |
| Cutout Width (mm): | 30 |
Find a compatible driver
We provide an easy-to-use online tool to calculate which LED drivers are compatible with your chosen luminaire. Follow the steps to determine the right driver for you.
More in the Collection
| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1212007 |
|
2W LED | 3000K | 90 | 70.0 | IP20 | Wired In | Control Gear Dependent | - | - | - | - | - | - |
| 1212027 |
|
2W LED | 2700K | 90 | 76.0 | IP20 | Wired In | Control Gear Dependent | - | - | - | - | - | - |
| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1212008 |
|
2W LED | 3000K | 90 | 80.0 | IP20 | Wired In | Control Gear Dependent | - | - | - | - | - | - |
| 1212028 |
|
2W LED | 2700K | 90 | 70.0 | IP20 | Wired In | Control Gear Dependent | - | - | - | - | - | - |
| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1212040 |
|
2W LED | 2700K | 90 | 46.0 | IP20 | Wired In | Control Gear Dependent | - | - | - | - | - | - |
| 1212038 |
|
2W LED | 3000K | 90 | 56.0 | IP20 | Wired In | Control Gear Dependent | - | - | - | - | - | - |
| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1212039 |
|
1W LED | 3000K | 90 | 21.8 | IP20 | Wired In | Control Gear Dependent | - | - | - | - | - | - |
| 1212037 |
|
1W LED | 2700K | 90 | 29.3 | IP20 | Wired In | Control Gear Dependent | - | - | - | - | - | - |
| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1212041 |
|
2W LED | 3000K | 90 | 84.0 | IP20 | Wired In | Control Gear Dependent | - | - | - | - | - | - |
