Tivola LED
Textured Grey 1338009
Forward voltage per product is 2.8V.
spec overview
Lamp Included 1 x 2W LED IP65To find out more about the material used for this product and how to maintain it to the best condition, please download our care and cleaning guide.
To ensure you have the correct amount of fittings per driver, please refer to our driver calculator. Alternatively, for more information on drivers, please refer to our Advanced Guide to LED Lights & Drivers.
Specification
| Lamp Required: | No |
|---|---|
| Lumen Output (LM): | 82.0 |
| Colour Temperature (K): | 3000 |
| CRI: | 90 |
| Max Lamp Type & Wattage: | 1 x 2W LED |
| Switched: | No |
| Dimmable: | Yes (Control Gear Dependent) |
| Type Of Dimmer: | Control Gear Dependent |
| Driver Required: | Constant Current 700mA |
| Class: | Class III - Low Voltage |
| Power Connection Type: | Wired In |
| IP Rating: | IP65 |
| Bathroom Zone: | Zone 1, 2, 3 |
| Recess Depth (mm): | 30 |
| Cutout Shape: | Round |
| Hole Saw Diameter: | 62mm / 2-7/16in |
Find a compatible driver
We provide an easy-to-use online tool to calculate which LED drivers are compatible with your chosen luminaire. Follow the steps to determine the right driver for you.
