Pinhole Slimline Round Fixed Fire-Rated IP65
Matt White 1434001
spec overview
Lamp sold separately 1 x 6W Max LED GU10 IP65 Fire RatedSpecification
| Lamp Required: | Yes |
|---|---|
| Lumen Output (LM): | Lamp Dependent |
| Colour Temperature (K): | Lamp Dependent |
| Max Lamp Type & Wattage: | 1 x 6W Max LED GU10 |
| Maximum Lamp Length (mm): | 73 |
| Switched: | No |
| Dimmable: | Yes |
| Driver Required: | No |
| Class: | Class II - Double Insulated |
| Power Connection Type: | Wired In |
| IP Rating: | IP65 |
| Bathroom Zone: | Zone 1, 2, 3 |
| Fire Rated: | Yes |
| Installation Orientation: |
Ceiling Mount Install after plastering |
| Recess Depth (mm): | 150 |
| Cutout Shape: | Round |
| Hole Saw Diameter: | 70mm / 2-3/4in |
Downloads
View compatible lamps
View compatible accessories
More in the Collection
| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1434005 |
|
2 x 6W Max LED GU10 | - | - | Lamp Dependent | IP20 | Wired In | Lamp Dependent | - | - | - | - | - |
| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1434006 |
|
3 x 6W Max LED GU10 | - | - | Lamp Dependent | IP20 | Wired In | Lamp Dependent | - | - | - | - | - |
| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1434008 |
|
6W Max LED GU10 | - | - | Lamp Dependent | IP20 | Wired In | Lamp Dependent | - | - | - | - |
| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1434007 |
|
6W Max LED GU10 | - | - | Lamp Dependent | IP65 | Wired In | Lamp Dependent | - | - | - | - | - |
| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1434002 |
|
6W Max LED GU10 | - | - | Lamp Dependent | IP65 | Wired In | Lamp Dependent | - | - | - | - | - |
| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1434003 |
|
6W Max LED GU10 | - | - | Lamp Dependent | IP20 | Wired In | Lamp Dependent | - | - | - | - |
| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1434004 |
|
6W Max LED GU10 | - | - | Lamp Dependent | IP20 | Wired In | Lamp Dependent | - | - | - | - |
