Pinhole Slimline Round Fixed Fire-Rated IP65

Matt White 1434001

spec overview

Lamp sold separately 1 x 6W Max LED GU10 IP65 Install after plastering
full spec
Fire Ratings

For more detailed information regarding fire rating requirements and Astro's test procedures, please view our guide.

Product Care and Cleaning Guide

To maintain this product to its best condition, please download our care and cleaning guide.

Specification

Lamp Required: Yes
Max Lamp Type & Wattage: 1 x 6W Max LED GU10
Maximum Lamp Length (mm): 73
Switched: No
Dimmable: Yes (Lamp Dependent)
Driver Required: No
Class: Class II - Double Insulated
Power Connection Type: Wired In
IP Rating: IP65
Bathroom Zone: Zone 1, 2, 3
Fire Rated: Yes
Installation Orientation: Ceiling Mount
Install after plastering
Recess Depth (mm): 150
Cutout Shape: Round
Hole Saw Diameter: 70mm / 2-3/4in
