Leros Trimless LED

Matt White 1342002

Please refer to our Advanced Guide to LED Lights & Drivers for more information.

Forward voltage per product is 3.05V.

This product must be installed before final plaster skim.

Back box not required for solid wall installation.

Product information

Colour Temperature (K):

2700

IP Rating:

IP20

CRI:

80

Dimmable:

Yes

More product information

Downloads and Support

Where can I buy Astro?

Support and Information

Finish:

Matt White

Lamp Included:

Yes

Lamp Type & Wattage:

1 x 1W LED

IP Rating:

IP20

Bathroom Zone:

Zone 3

Class:

Class III - Low Voltage

Lumen Output (lm):

35.6

Colour Temperature (K):

2700

Driver Required:

Constant Current 350mA

Dimmable:

Yes

Type Of Dimmer:

Control Gear Dependent

Switched:

No

Dimensions:

H: 90
W: 90
D: 42mm

Installation Orientation:

Wall Mount

Light Source Type:

LED

CRI:

80

Cutout Length:

75

Cutout Width:

45

Recess Depth:

45

Will I need a driver for this light?

Yes, this product will require a driver.

Why do I need a driver?

A compatible LED driver must be used between the switched mains supply and the LED light. If connected directly to the mains voltage supply, this will cause permanent damage to the LED, requiring replacement of the entire LED light fitting.

Enter product code and quantity

Product Code

Product Qty

Follow the steps to determine the right driver for you. Do you want to Dim your lights?

Yes

No

What type of dimmer are you using?

Not sure which type of dimmer you have? Don't worry, consult a qualified electrician or the manufacturer of the dimmer switch or system. It is important you are sure before proceeding.

Astro recommends

Want more information? Take a look at our guides:

Basic Guide, Advanced Guide

Loading…

Sorry, there are no compatible drivers based on your current search criteria.

Please go back and try again.

Non Dimming Drivers

Other non dimming drivers available Hide alternative drivers

Dimming Drivers

The list of drivers below are dimmable but can also be used in non dimming situations.

Other dimming drivers available Hide alternative drivers

Driver

LED Driver CC 250/350/500/700mA DALI Dim

code: 6008020

LED Driver CC 250/350/500/700mA DALI Dim

Code

6008020

Code	Finish	IP Rating	Colour Temp.(K)	Wattage	CRI	Features

6008020	-	-	-	Lamp excl	-	-

View as:

LED Driver CC 350/500/700mA 1-10V Dim

code: 6008058

LED Driver CC 350/500/700mA 1-10V Dim

Code

6008058

Code	Finish	IP Rating	Colour Temp.(K)	Wattage	CRI	Features

6008058	-	-	-	Lamp excl	-	-

View as:

LED Driver CC 350mA 1.1-10.5W 1-10V Dim

code: 6008013

LED Driver CC 350mA 1.1-10.5W 1-10V Dim

Code

6008013

Code	Finish	IP Rating	Colour Temp.(K)	Wattage	CRI	Features

6008013	-	-	-	Lamp excl	-	-

View as:

LED Driver CC 350mA 2.8-4W

code: 6008052

LED Driver CC 350mA 2.8-4W

Code

6008052

Code	Finish	IP Rating	Colour Temp.(K)	Wattage	CRI	Features

6008052	-	-	-	Lamp excl	-	-

View as:

View 5 more drivers
